Phillips I2C2002 evaluation board kit


Phillips I2C2002 evaluation board kit
Philips I2C 2002-1 Evaluation Board I2CPORTv2.0 printer port adapter
I2C2002-1Akit is a special bundled kit consisting of the Win-I2CNT software and the I2C 2002-1A Evaluation Board from
NXP (Philips) Semiconductors that enables easy programming and evaluation of the included PCA95xx I2C devices.
The complete kit includes the new I2C2002-1A Evaluation Board, I2CPortv2.0, Win-I2CNT software, USB cable adapter card
for demonstrating I2C buffer capabilities (USB cable only used for connector convenience, not for USB connectivity), 4-wire
I2C cable and a universal mains(100-240v AC) power supply. Note: European AC plug adapters are not included.
Win-I2CNT v4 version runs on WindowsTM 95, 98, ME, NT4.x, 2000, and XP PC platforms and includes dedicated
support for over 45 NXP (Philips) Semiconductors' I2C devices, user-defined I2C/SMBus devices, custom user controls, ascii file
output, and hex file support for I2C EEProm programming.
The I2C 2002-1A Evaluation Board demonstrates the capabilities of the following devices: PCA9501, PCF8574, PCA9561,
PCA9543, PCA9554/5, PCA9550/1, PCF8582, PCA9515, and P82B96. NXP documentation and Application Notes for
the Evaluation Board and ICs is included on the CD with the Win-I2CNT software.
The printer port adapter (I2CPORTv2.0) was designed specifically for Win-I2CNT and includes 3 different I2C header
configurations, on-board socketed 256byte I2C EEprom (PCF8582) for easy EE programming; and jumper selectable
5 or 3.3 volt capabilities to accommodate I2C busses of either supply voltage.
- Win-I2CNT software/documentation/Philips Evaluation Board appnotes on CD
- I2C2002-1A Philips Evaluation Board
- I2CPortv2.0 adapter (for Win-I2CNT)
- P82B96 adapter card (I2C bus buffer IC)
- Universal AC input wall-plug 9v DCswitching power supply
- QuickStart Guide installation sheet
I2C Devices supported in Win-I2CNT
Documentation updates are available from the NXP website:
http://www.standardics.nxp.com/support/boards/i2c20021/
I2C2005-1 Evaluation board application note:
http://www.standardics.nxp.com/support/documents/i2c/pdf/an10146.pdf
(Phillips I2C2002 evaluation board kit was posted and is owned by: Edith Williams)
Contact: Edith-Williams@chicagopartsnetwork.com (Edith Williams) (actual email hidden)
Contact Edith-Williams@chicagopartsnetwork.com (Edith Williams) for more information.
