* Model / Part #: GLF6101-SM4S The Gaskleen 6101 Series Filter Assembly is designed for 3 nanometer (0.003 m) filtration of process gases. * 316L stainless steel electropolished housing * Available in both standard and shortened version * Wide variety of fitting options available * Compact size (2.2"/56mm dia.) for ease of installation * Cleanroom manufactured and packaged * Electropolished 316L stainless steel housing * 25 in / 0.64 m Ra internal surface finish * Emflon element: 100% integrity tested * Core and end caps: Polypropylene * O-ring: Teflon1 encapsulated Viton1 Filter Area: 464 cm2 / 0.5 ft2 * 1 4" Gasket Seal, Male (VCR2 or compatible) * 1 4" Compression Seal (Swagelok2 or compatible) * 3 8" Gasket Seal, Male (VCR or compatible) * 3 8" Compression Seal (Swagelok or compatible) * 1 4" Female pipe thread Operating Conditions * Maximum Operating Pressure: 750 psig @ 176 F/52 bar @ 80 C * Maximum Forward Differential Pressure: 100 psid @ 70 F/7 bar @ 21 C * Maximum Reverse Differential Pressure: 50 psid @ 70 F/3.4 bar @ 21 C * 100% helium leak tested to 10-7 atm cm3/s * Design validated to 10-9 atm cm3/s * Outer bag: aluminized mylar For further specifications, please visit Pall's online brochure at http:// /pdf/A5c_Gaskleen_6101_Series.pdf (New pall gaskleen 6101 GLF6101SM4S gas filter 003 µm - was posted and is owned by: Marian Wiley) |
