Manufactured by Flow Line for CMT these 2-wire, ultrasonic transmitters provide non-contact level measurement. They are ideally suited for challenging ultra pure, corrosive, slurry or waste liquids. The transmitter is typically selected for small atmospheric process vessel, IBC tote, 55-gallon drum and waste sump applications. Also great for fish tanks, brewing, and many other applications. TGUS204 which measures vessels up to 4 feet deep. TGUS210 which measures vessels up to 10 feet deep. Accuracy: 0.15% of span in air Loop resist.: 600 ohms @ 24 VDC Signal output: 4 20 mA, two-wire Calibration: Target, wiring polarity Fail-safety: Reverts to 22 mA Process temp.: -40 F to 160 F; -40 C to 71 C Electronics temp.: -40 F to 160 F; -40 C to 71 C Enclosure rating: NEMA 6X (IP67) Pressure: 30 psi (2 bar) @ 25 C., derated @ 1.667 psi (.113 bar) per C. above 25 C. Installed height: 1.7" (4.3 cm) above tank process mount Cable jacket mat.: Polypropylene Cable type: 2-conductor, shielded Process mount: 1" NPT (1" G) Mount. Gasket: Viton (G version only) Classification: General purpose CE compliance: EN 50082-2 immunity, EN 55011 emission Flowline Model #LU05 is the CMT TGUS 204 Ultrasonic level transmitter 4 Flowline Model #LU12 is the CMT TGUS 210 Ultrasonic level transmitter 10 Please inform us of which transmitter you would like. Either the TGUS 204 or the TGUS 210. The products are new, unused, working condition. Warranty: 30-day unconditional money back guarantee. 1-year replacement guarantee *Sold for over $400 elsewhere. (Ultrasonic tank transmitter was posted and is owned by: Lorie Harrell) |
L_harrell@chicagopartsnetwork.com (Lorie Harrell) for more information.
