ONLY ONE TIME WRITE MICROCHIPS PIC16F72 I/SP. NO SOLDERING, ONLY INSERT SOCKET. It was made in THAILAND at 2003 or 2004. Only 35 single word instructions to learn All single cycle instructions except for program branches which are two-cycle Operating speed: DC - 20 MHz clock input DC - 200 ns instruction cycle 4K x 14 words of FLASH Program Memory, Up to 192 x 8 bytes of Data Memory (RAM) Pinout compatible to the PIC16C73B/74B/76/77 Pinout compatible to the PIC16F873/874/876/877 Interrupt capability (up to 12 sources) Eight level deep hardware stack Direct, Indirect and Relative Addressing modes Processor read access to program memory In-Circuit Serial Programming(ICSP) via two pins Timer1: 16-bit timer/counter with prescaler, can be incremented during SLEEP via external crystal/clock 8-bit, up to 8-channel Analog-to-Digital converter Synchronous Serial Port (SSP) with SPI(Master mode) and I2C(Slave) Universal Synchronous Asynchronous Receiver Transmitter (USART/SCI) Parallel Slave Port (PSP), 8-bits wide with external RD, WR and CS controls (40/44-pin only) Low power, high speed CMOS FLASH technology High Sink/Source Current: 25 mA Industrial temperature range - < 1 A typical standby current (Pic 16F73 i/sp, 28PIN dip , 10PCS , only 1 time write was posted and is owned by: Enrique Becker) |
