Click picture to see actual image size. Agilent (Hewlett Packard) 8566A/B Spectrum Analyzer Complete System Cosmetic Condition: Good. Has minor scratches, and sticker residue on the unit. Testing Notes: Tested To Be In Working Condition. Accessories Included: Two Power Cords, Interconnect Cables. Sold: Five Day Right of Return. The 8566B high-performance, 100 Hz to 22 GHz, microwave spectrum analyzer for bench and ATE use. The exceptional frequency stability of the 8566B permits measurements with a 10 Hz bandwidth. This narrow resolution bandwidth yields noise levels as low as -135 dBm. Excellent frequency stability, sensitivity, and frequency reference accuracy combine to allow very accurate measurement of small signals in the presence of large ones. Multiple traces can be displayed to measure residual FM or drift, or to conduct real-time surveillance over a wide frequency range. Analyzer control settings can be saved in non-volatile memory. Complex measurement routines can be created on an external controller, stored in the analyzer's user RAM, and executed using a single custom softkey. ***This is an upgraded HP 8566A to meet HP 8566B specifications*** Frequency range 100 Hz to 22 GHz * Resolution bandwidth 10 Hz to 3 MHz in a 1, 3, 10 sequence * 2 to 22 GHz preselected range * Measurements to 325 GHz with external mixers * Exceptional frequency stability and sensitivity * Up to four trace markers with amplitude and frequency readout * Stores traces, instrument states and custom downloadable programs (DLPs) * 100, 120/200, 220, 240 Vac; 50-60 Hz operation WE GUARANTEE ITEM CONDITION AS STATED UNDER "CONDITION" ABOVE. SELLER EXPRESSLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT. * Most items have some cosmetic imperfections such as: scratches, dents, cracks, sticker residue, and discoloration due to normal wear and tear. Sales Tax of 8.8% is charged to all Washington State Purchases unless you present a valid tax exemption certificate. Items are not available for local pickup. If we find the item returned is not the item sent (different serial number or other identifying mark), we will consider that a fraud attempt and no refund will be issued. * We guarantee that the item will work only as described in the "Testing Notes" above. There may be an underlying problem(s) that we are truly unaware of and these are not covered. If you discover that the item received is not as represented in the "Testing Notes", you must notify us within 48 hours of receiving the item. Defective items will be replaced or repaired. A refund will only be issued if the item cannot be replaced or repaired. * Sales Listed "5 Day Right of Return ": (Hp 8566A/b spectrum analyzer with display complete was posted and is owned by: Philip Vaughn) |
philip_vaughn@chicagopartsnetwork.com (Philip Vaughn) for more information.
