4H60 devlieg jig mill


4H60 devlieg jig mill
Spindle Diameter .............. 4"
Taper In Spindle .............. #50
Vertical Travel Of Headstock .. 48"
Cross Travel Of Table ......... 60"
Platten Travel (In & Out) ..... 20"
Spindle Travel (In & Out) ..... 20"
Table Size .................... 40" x 60"
Spindle Speeds (16) ........... 52-1000 RPM
Spindle Feeds (8) ............ .002-.024 IPR
Milling Feeds (16) ........... .5-36 IPM
Rapid Traverse (2) ............ 50 & 150 IPM
Dimensions: 185" L-R x 153" F-B x 116" High
