31.5" Starrett HCS800 CNC OPTICAL COMPARATOR, QC4205 C 31.5" Screen Starrett HCS800 CNC OPTICAL COMPARATOR, QC4205 CNC w/INTERNAL EDGE DET., 31.50" Starrett CNC Horizontal Projection Floor Model Optical Comparator Model: No. HCS800 CNC S/N: 0014 NEW: 1997 Vertically correct and unreversed image 5-position motorized internal lens turret Constant 9-1/4" (231mm) front working distance (regardless of magnification) 20" (500mm) horizontal travel and 10" (250mm) Nickel plated steel stage with cross roller 32" x 8" (800x200mm) staging area Screen-mounted overlay chart clips Frosted glass screen with crosshairs, Profile illumination - high-power, fan- cooled, mercury arc lamp with yellow/green Surface illumination - through the lens Helix angle stage adjustable +/- 15 Built-in digital protractor with DD/DMS Heidenhain .00005" (.001mm) resolution Centrally mounted vertical (Y-axis) scale Threadless X-axis quick-release for "zero" Internal optical edge detection Optional extended canopy and new curtains Projection lens: 10x, 20x, and 50x This machine is in very good condition. The LS Starrett Co's HC 800 optical measuring projector is said to provide the largest standard workstage (20" horizontal and 10" vertical measuring travel) in the industry. The floor-standing unit has a large, 32" (800 mm) screen. Tungsten-halogen profile illumination (24 V, 100 W) provides bright, clear, contrasting images. On-axis surface illumination (24 V, 500 W) comes directly through the lens, eliminating the need for oblique lighting or fiber optics. It's digital rotary screen allows for direct angle display. Incremental or absolute screen position can be selected by the operator and the display can be switched between decimal, degrees, and degree-minutes, with resolution of 0.01 deg or 1 min of arc. ** Like New Condition & Appearance ** (31.5" starrett HCS800 cnc optical comparator, QC4205 c was posted and is owned by: Kayla Wilson) |
kayla-wilson@chicagopartsnetwork.com (Kayla Wilson) for more information.
