11" Y 18" X Moore G-18 JIG GRINDER, HARD WAYS & SCREWS, 11" Y Axis 18" X Axis Moore G-18 JIG GRINDER, HARD WAYS & SCREWS, OIL BATH FOR SCREWS, TABLE SIZE .................................. 11" X 24" TABLE TRAVEL (LONGITUDINAL).................. 18" TABLE TRAVEL (CROSS) ........................ 11" SPINDLE HOUSING VERTICAL TRAVEL ............. 12- 5/8" SPINDLE VERTICAL TRAVEL ..................... 3- 5/8" TABLE TOP TO WHEEL COLLET ................... 2" X 18" SPINDLE TO COLUMN WAYS ...................... 10" SPINDLE TO COLUMN BELOW WAYS ................ 13-1/2" INFINITELY VARIABLE SPINDLE SPEEDS ...... 25 TO 225 RPM INFINITELY VARIABLE SPINDLE FEEDS ........ 2 TO 120 SPM SPINDLE FEED ADJUSTABLE FROM ......... 0.100" TO 3- 5/8" GRINDING WHEEL SPEEDS ............. 6,000 TO 175,000 RPM GRINDING CAPACITY (HOLE DIA.) ........ 1/64" TO 3- 1/2" WITH EXTENSION PLATE ...................... 13- 1/2" MAIN SPINDLE SLIDE ADJUSTMENT .............. 1-1/2 DEG. APPROXIMATE WEIGHT .......................... 4,000 LBS APPROX. FLOOR SPACE REQUIRED ..... 58"LR X 59"FB X 91"H MINIMUM HEIGHT WITH HEAD IN DOWN POSITION ......... 86" ELECTRONIC SERVO DRIVE PROVIDES INFINITELY VARIABLE SPINDLE SPEEDS (25 TO 225 RPM) HARDENED, GROUND & LAPPED NITRALLOY LEAD SCREWS LEADSCREWS & NUTS ARE FULLY IMMERSED & OPERATE IN A 1/5 H.P. D.C. MOTOR (MAIN SPINDLE) MOORE JIG GRINDING HEADS ..... CHOICE OF 40K OR 60K RPM. PRESENTLY, THE MACHINE HAS A 40K RPM HEAD. MACHINE IS WIRED FOR 220 VOLTS/1 PHASE/60 CYCLE ELECTRICS ** EXCEPTIONAL CONDITION - ORIGINAL PAINT!! ** (11" y 18" x moore g-18 jig grinder, hard ways & screws, was posted and is owned by: Fay Benton) |
F-Benton@chicagopartsnetwork.com (Fay Benton) for more information.
