Kistler 5134 4 Chan Peizotron Power Supply/Coupler/Amp * RS232C interface for remote control and monitoring * Sensors circuit open/short alarm * Non volatile memory for set parameters * Seven selectable gains 1x, 2x, 5x, 10x, 20x, 50x, 100x * Four selectable low-pass filters * Bias voltage monitor ON/OFF Description (from an online brochure) "The Kistler 5134 is flexible, simple to use signal conditioner that provides excitation power, signal tailoring and acts as an interface between voltage mode piezoelectric and measuring instruments. This microprocessor controlled coupler provides power and signal processing to four channels of Piezotron, PiezoBeam, K-Shear and Ceramic Shear Accelerometers or any voltage mode piezoelectric sensor operating with constant current excitation (2-wire system). "An LCD display and keyboard allows easy selection of gain and filters for each channel individually. LED's show the unit's status and signal error in the case of a detected problem with bias voltage or the cable integrity. Additionally, the RS232C interface allows remote control all functions of the unit. The unit's very low noise floor makes it particularly useful for general vibration lab use with single axis or triaxial accelerometers." (Kistler 5134 4 chan peizotron power supply/coupler/amp was posted and is owned by: Jeannine Burnett) |
jeannine_burnett@chicagopartsnetwork.com (Jeannine Burnett) for more information.
