Hantek DSO1060 Handheld Scope Meter 60mHz 2 Channel 2CH Resistance: 1M ; Capacitance: 15 pF 32k at Single Channel, 16k at Dual Channel Edge, Pulse Width, Alternative Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot Frequency,Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Delay time from ch1 rising edge to ch2 rising edge Delay time from ch1 falling edge to ch2 falling edge Manual, Track, Auto Measure Modes CH1+/- CH2, CH1xCH2, CH1/CH2, FFT, Invert Voltage, Current, Resistance, Capacitance,Diode & Continuity 5.7 Inch with LED Backlight Display 240 (Vertical) x 320 (Horizontal) Dots USB Host / Device 2.0 Full Speed Supported AC 100V ~ 240V, 50Hz ~ 60Hz; DC Input: 8.5VDC, 1500mA Oscilloscope and Multimeter Independence Characteristic(Handheld Scopemeter/Oscilloscope/Multimeter) * l Excellent Industrial Design .Direct key for Each Channel ,Time base ,Trigger and DMM,easy to operate. * l Large 5.7 inch TFT Color LCD Display ,Led backlight,Display clearly. * l USB Host/Device 2.0 full-speed interface ,support removeable disk, RS-232/LAN Optional ,Easy to control by PC or long-distance. * l High Bandwidth 60MHz-600MHz Oscilloscope ,and 6000 COUNTS high precision DMM. * l High refresh rate High Real-time Sample Rate 150MS/s-2GS/s, 50GS/s Equivalent-time Sample Rate. * l FFT , + , - , * , / ,X-Y, 22 kinds of auto measurements, PASS/FAIL Check ,easy to use on production line. * l Multiform Trigger mode ,2 separate Time Base in ALT Trigger mode ,easy to see 2 signal with different frequency. * l 1000 waveforms save and record. * l Battery Power Operation (Installed) Industrial Design. * l Save waveform in the following: jpg/bmp graphic file, MS excel/word file. * l Dimensions (mm):240(L)x165(W)x50(H), be carried easily. * l Labview\VB\VC Second Design instance. Operating system: Windows NT, Windows 2000, Windows XP ,VISTA Supply DEMO code (VC VB LABVIEW) Connected to the computer can be used as a virtual oscilloscope 6000 COUNTS Digital Multimeter 22 kinds of waveform measurements ALT MAG, easy to search for signal FFT Provide spectrum analysis function ALT trigger mode, dual time base, easy to observe two signals of different frequency Test signal more than 100MHz by ETS mode Document management, and convenient file storage and management (Hantek DSO1060 handheld scope meter 60MHZ 2 channel 2CH was posted and is owned by: Candice Simon) |
