30" OGP OQ-30S OPTICAL COMPARATOR, DI-METRIC PLUS DRO, 30" Screen OGP OQ-30S OPTICAL COMPARATOR, DI-METRIC PLUS DRO, PROJECTRON III EDGE DET. 30" OPTICAL GAGING PRODUCTS, INC. (O.G.P.) HORIZONTAL PROJECTION FLOOR TYPE OPTICAL COMPARATOR MODEL: OQ-30S S/N: 300615 NEW: 1988 SCREEN DIAMETER ............................ 30" ANGULAR (GRADUATED PROTRACTOR W/VERNIER TO 1' OF ARC) ............................. 360 DEG. TABLE SIZE ................................. 8" X 32" TABLE LOAD CAPACITY ........................ 500 LBS. TABLE TRAVEL, HORIZONTAL ................... 12" TABLE TRAVEL, VERTICAL ..................... 10" FOCUS TRAVEL ............................... 3" HELIX ROTATION (TO 5 DEG. ARC) ............. +/- 15 DEG. THR0AT CLEARANCE ............................ 30" STAGING CENTERS (5"DIA. CAPACITY)- MAX. LENGTH OF PART:...................... 25" DISTANCE COLLIMATOR TO FOCUL PLANE:......... 13" WORKING DISTANCE, FOCAL PLANE TO FRONT RELAY LENS HOUSING ........................ 17" WITH HELIX (MAX./MIN.) .................... 10- 3/4"/3/4" WITHOUT HELIX (MAX./MIN.) ................. 12"/2" WITH HELIX (MAX./MIN.) ................. 44- 1/4"/34- 1/4" WITHOUT HELIX ............................. 43"/33" APPROX. DIMENSIONS ......................... 90"F-B X 72"W APPROX. MACHINE WEIGHT ..................... 3,150 LBS. OGP "DIMETRIC-PLUS" 2-AXIS DIGITAL READOUT DISPLAY WITH PROGRAMMABLE GEOMETRIC FUNCTIONS OGP "PROJECTRON III" EDGE DETECTION ELECTRONIC DIGITAL PROTRACTOR FOR THE CHART ROTATION MERCURY ARC LIGHTING FOR BOTH PROFILE TELECENTRIC RELAY LENS SYSTEM & MIRRORS FOR ERECT, POWER TABLE (LEFT TO RIGHT) (UP AND DOWN) W/INFINITELY HEAVY DUTY TABLE w/500 LBS. LOAD CAPACITY 6- POSITION POWER LENS TURRET W/(3) LENSES HI-MAG COLLIMATOR, PART #423710 OVERHEAD HOOD & CURTAIN ASSEMBLY ** INSPECT UNDER POWER IN CHARLOTTE, NC ** (30" ogp oq-30S optical comparator, di-metric plus dro, was posted and is owned by: Madelyn Mckenzie) |
