NEW PORTABLE CAPSTAN WINCH WITH 6' ANCHOR SLING The Portable Winch is built for industrial use, featuring full size gearing and ball bearing construction in a lightweight aluminium housing. The winch weighs only 28 lb and is easily carried wherever its pulling power is needed. The Portable Winch has numerous applications in forestry, tree care, construction, electrical installations, ATVing, boating, aviation and rescue operations, to name a few. The Portable Winch is CE rated for use in other countries. A Portable Winch? can be used continuously, without overheating. The Honda GXH-2.5 HP, 4-stroke gas engine will deliver dependable power, no matter what temperature it is, for as long as you need. Electric winches typically are rated for 20% duty cycle, with a maximum of one minute on and four minutes cooling down. When you factor in their low speed (10-15 feet/minute at maximum load capacity), you won't get much done before it's time to stop and let the motor cool down. With a Portable Winch?, you also get your work done quickly, at the speed you choose. At the maximum rated pull of 2500 lb, your winching speed will be about 25 feet per minute. If you only pull 1500 lb load, you will be winching close to 40 feet per minute. You can also adjust the throttle on the Honda engine, to regulate speed and power. For applications requiring a lower pull rate and higher speed, the optional 'big drum' will bring max speed to about 60 feet per minute, and lower the maximum load pull to about 1300 lb. Application such as pulling wire through conduits, skidding small logs, hauling game, etc. can take advantage of this unique feature from Portable Winch?. To anchor your Portable Winch?, simply hook the heavy-duty, 2'' wide, 6' long sling to the safety hooks at the rear of the winch. If you plan to anchor from your vehicle's ball hitch, order the optional hitch plate which slides onto the ball's neck, another Portable Winch? exclusive feature. If you need to pull extra heavy loads, Portable Winch? offers a snatch block kit including a swing-side pulley and locking steel carabiner. The pulley is attached to the load with the carabiner, and the rope is attached back to the winch anchor. This lightweight system effectively doubles the pulling power of the winch to an amazing 5000 lb line pull! (Portable capstan winch tree tower construction climbing was posted and is owned by: Paige Hutchinson) |
PHutchinson@chicagopartsnetwork.com (Paige Hutchinson) for more information.
