- While there are 6 crosses in the headstock; they are not all to be drilled. Instead; the two closest to the nut are NOT; the next 6 are to be drilled as a 3+3 to suit the WJ-303s; the rest of the holes are NOT to be drilled. I am after an overall effect like the attached without copying the headstock precisely - The BA6110/BA6110FS is a low-noise, low-offset programmable operational amplifier. Offering superb linearity over a broad range, this IC is designed so that the forward direction conductivity (gm) can be changed, making it ideal for applications such as voltage control amplifiers (VCA), voltage control filters (VCF) and voltage control oscillators (VCO); - Distortion reduction circuitry improves the signal-to-noise ratio by a significant 10dB at a distortion rate of 0.5% in comparison with products not equipped with this feature. When used as a voltage control amplifier (VCA), a high S/N ratio of 86dB can be achieved at a distortion rate of 0.5% - The open loop gain is determined by the control current and an attached gain determining resistance RL, enabling a wide range of settings. - In addition, a built-in low-impedance output buffer circuit reduces the number of attachments. (Ics chips: 1 pcs BA6110 BA6110FS op amp was posted and is owned by: Alyson Whitfield) |
