DESCRIPTION: * Sadelco MiniMax M800 CATV/RF Cable Signal Level Tester 5-872MHz Scanning Signal Level Meter with AC Adapter EIA (NTSC), HRC, IRC, AIR-VHF, UHF, FM, PAL and Custom Channel Plans available on request. IF Bandwidth : 280 KHz at 3 dB points FM Selectivity : Will distinguish 2 FM signals of similar amplitude 300 KHz apart. Measurement Range: -20 + 40 dBmV (+40 to +100dBuV) Amplitude Accuracy: + 1.0 dB at 77 F Auto Calibration: Each measurement computer corrected for level, attenuator setting and temperature Internal Calibrator: + 0.25 dB, 4.5 - 864 MHz white noise source Digital LCD: Indicates channel, frequency and signal level in dBmV (switchable to dBuV) Analog Microammeter: Indicates real time signal level for easy antenna orientation, + 1.5dB. Range: 20 dB computer corrected Input: 75 ohm, user replaceable F81 connector, BNC available on request. Power Out: Built-in battery provides switchable 18V at F connector for powering downconverters C/N: range > 50 dB with external preselector Hum: 0.5 - 5%, + 0.3%, detects all hum up to 600 Hz. Favorite channels: 9 user programmable channels Delta PA: Automatically calculates and displays difference between picture and audio levels of same channel. Audio: Adjustable volume, waterproof mylar speaker. Illumination: Switchable lights for both LCD and Microammeter Battery Test: Shows battery voltage and elapsed time Power Supply: Built-in NiCads provide >16 hours of normal intermittent use Electronic Sut-off: User adjustable, 5 min, 10 min or continuous Digital Channel Measurement: Measures average power of QAM signals Dimensions: 8.5" L x 4" W x 3" D (* sadelco minimax M800 catv/rf cable signal level test was posted and is owned by: Raymond Ayala) |
