Octagon 5710 Analog I/O 8-Bit ISA Data Acquisition Card (Used) The 5710 provides a versatile platform for mixed analog/digital environments. With 16 analog input channels and 19 digital 1/0 channels, it can monitor and control a wide variety of conditions simultaneously. Micro PC cards plug into any ISA expansion slot or Micro PC card cage. 40 to 85 C operating; 55 to 95 C nonoperating 40g shock, 5g vibration, 3 axis The Micro PC controllers, expansion cards and card cages provide a complete solution for applications in transportation, security, military, communications, distributed control, point-of-sale, ticketing machines, weighing equipment, and similar application. Part Number: 3181 Size (inches): 4.5" x 4.9" Revision: 3.47 Size (mm): 114.3 x 124.46 Digital I/O: 3 dedictated outputs, 16 configurable I/O Form Factor: Micro PC Analog Outputs: two, 12-bit Output levels: 0-5V, 5V, 0-10V Analog Inputs: 16 single-ended or 8 differential Input levels: 50 mV, 500 mV, 5 V Power: 80 mA typical Sampling rate: 33,000/70,000 per second Temp. Range: 40 to 85 C Number of counter/timers: 3 Shock: 40g Maximum count rate: 40,000/sec Vibration: 5g Operating modes: 6 More Support and Downloads HERE * (1) Octagon 5710 Analog I/O 8-Bit ISA Data Acquisition Card Used; In Excellent Physical Condition - Looks like somebody added the ISA Slug to it, in the factory picture it does not have one. The card looks very good. (See Photos) (Octagon 5710 analog i/o 8-bit isa data acquisition card was posted and is owned by: Lucy Ramos) |
