0.19" Dia. 2.5" L Hartford 0/400/R up to .190" THREAD R 0.19" Dia. 2.5" Long Hartford 0/400/R up to .190" THREAD ROLLER, 0-400R HARTFORD HIGH SPEED FLAT DIE THREAD ROLLER MODEL: 0-400R S/N: 4-278-15 NEW: 1964 SCREW DIA. CAP. ........ #2 (.086) THRU #10 (.190) THREAD LENGTH CAP. ..... 1/8" UP TO 2-1/2" DIE POCKET DEPTH ....... 3-1/8" BLANK LENGTH ........... UP TO 3" HOPPER CAPACITY ........ 750 CUBIC INCHES, 100 POUNDS STARTER FINGERS SUPPLIED COMPLETE SET #2 THRU #10 COOLANT PUMP ........... 1/10 HP, 3600 RPM, 330/440-3.60 MAIN DRIVE MOTOR ....... 5 HP, 1800 RPM, 220/440-3.60 HOPPER DRIVE MOTOR ..... 1/4 HP, 1800 RPM, 220/440-3.60 FLOOR SPACE REQUIRED ... 4' x 6' NET WEIGHT ............. APPROXIMATELY 2,900 POUNDS PRODUCTION RATE - INFINITELY ADJUSTABLE FROM 135 TO 400 ADJUSTABLE FEED RAIL HEIGHT - COMPLETE ASSEMBLY, INCLUDING HOPPER, MOVES UP, DOWN FOR VERTICAL ADJUSTMENT OF RAILS. EASY DIE MATCHING - SIMPLE ECCENTRIC CAM ADJUSTMENT CONTROLS RELATIVE POSITION OF MOVING DIE. AUTOMATIC SLIDE LUBRICATION - INDEPENDENT SYSTEM WITH OIL FLOW SIGHT GAGES, LOW OIL WARNING LIGHT AND AUTOMATIC TOOL-STEEL CLAD MAIN SLIDE - RIDES IN BRONZE LINED HOUSING DIE SPACING - PRECISELY ADJUSTED THROUGH LONGER SPACING STRAIGHT LINE FEED RAILS - MINIMIZE WEAR, PROVIDE TROUBLE FLAT DIES - FOR ECONOMY, LOW COST REPLACEMENT AND EASE OF HARTFORD AIR JET & VIBRATOR - FOR UNINTERRUPTED FEED ADJUSTABLE STARTER FINGERS - HEIGHT AND STROKE CAN BE VARIED WORKING PARTS VISIBLE - THROUGH INCLINED WORK TABLE, TILTED SEPARATE COOLANT SYSTEM - PERMITS USE OF PROPER COOLANT FOR HOPPER SPEED - INFINITELY ADJUSTABLE FROM 4.5 TO 11.5 RPM HOPPER - VINYL LINING REDUCES NOISE, PREVENTS BURNISHING OF HINGED LOADING CHUTE - PERMITS EASIER CLEANING OF HOPPER HANDWHEEL - FOR EASIER SET UP, GEARED AT 4:1 RATIO Click Here For More Hartford Machines (0.19" dia. 2.5" l hartford 0/400/r up to .190" thread r was posted and is owned by: Jocelyn Ayala) |
J_Ayala@chicagopartsnetwork.com (Jocelyn Ayala) for more information.
