~90cf Stainless double-cone blender counter-rotating tumble mixer dissolver * 47" discharge height with 10" gate-valve * 10 horse power geared tumble motor * 20 horse power mixer blender dissolver motor * non-magnetic stainless chamber paint on the outside * air powered vibrator shaker on discharge cone * chamber tumbles and blades inside rotate faster the opposite direction * ~4000 lbs, 125 by 79 by 125 inches raw Looks ready to use except missing the load port cover. If you do BIN price (not offer) we will come up with a cover and test the motors. The internal dissolver blades are driven from the rear end in the image above and can rotate opposite the drum tumble direction which is driven from the far end in the image above. Note the air powered vibrator in the image above. This unit was once brokered by Mohr Systems-#9544 Note the shinny stainless interior. The image below is looking in the load port at the discharge port. The mixer dissolver counter rotating shaft is in the middle. It is currently fitted with very small blades. This Might Be Just What You Need For Your serious process blender application. (90CF stainless double-cone blender tumble mixer disolvr was posted and is owned by: Hope Benton) |
hope_benton@chicagopartsnetwork.com (Hope Benton) for more information.
