HP/Agilent 3577A Network Analyzer w/35677A S-Test Set Exterior Dimensions (L"*W"*H"): 22 1/8 * 16 1/2 * 12 3/8 Hewlett Packard 3577A 5Hz - 200 MHz Network Analyzer Unit Powers on and is in excellent working condition. Includes HP 35677A S-Parameter Test Set +15 to -49 dBm (1.26 Vrms to 793m Vrms: 2dBV to -62 dBV) into a 50 load 1 dB at +15 dBm and 100 kHz. Below +15 dBm, add the greater of 0.02 dB/dB or 0.2 dB 1.5 dBp-p from 5 Hz to 200 MHz 50 ; > 20 dB return loss at all levels Linear, alternate, cw and log frequency; log amplitude 100 ms/span to 200 ms/span for frequency sweep; 1 ms/step to 16 s/step for amplitude sweep Free run, immediate, line, external -13 dBV from 10 kHz to 200 MHz with internal 20 dB attenuators ON (0dBm at 50 ) Selectable 50 with > 25 dB return loss, or 1 M in parallel with approximately 30 pF Selectable 1 kHz, 100 Hz, 10 Hz, or 1 Hz Sensitivity (Due to noise and internal crosstalk between source and receiver inputs) > 100 dB isolation between inputs Electrical Length/Reference Plane Extension Provides equivalent electrical line length, or delay at inputs A, B, and R. Range: -3 X 108 m to +3 X 108 m or +1 to -1 s 5 digits or 0.1 cm (3.3 Ps) whichever is greater 0.1 cm or 0.02% whichever is greater (Hp/agilent 3577A network analyzer w/35677A s-test set was posted and is owned by: Winifred Craft) |
Wcraft@chicagopartsnetwork.com (Winifred Craft) for more information.
