HDC-600B issue series Hall effect current sensor is applied principles of a new generation of current sensors Hall， Conditions of segregation in DC measurements, exchanges, and various irregular pulse waveform of the current. * Model / Parameters / Symbols HDC-600B * Rated current measurements 50A/100A/200A/300A/600A * Linear scope 0～150A/0～300A/0～600A/0～700A/0～800A * Export voltage Vh 4V1ï¼… at If * Zero current imbalances Vo 0.03V below at Ifï¼0 * Linear error p 1ï¼… of Vh at Ifï¼F.S * Export Wenpiao - 0.1%/℃ within at RL=10KΩ and If=F.S * 0.1 Wenpiao - 2.0mv/℃ 1.0mv/℃ within * Insulation voltage - 2.5KV AC with 50 or 60Hz 1minute * Insulation strength - 500MΩ Min at 500V DC * Working temperature C -10～80℃ E -40～85℃ * Storage temperature C -40～85℃ E -55～125℃ * Hull open ring current sensor * Good structure, no inserting-loss You must have a return authorization number to return your product. Please contact F.dotson@chicagopartsnetwork.com to obtain an authorization number, which shall be valid for 14 days after issued. This product is covered by a warranty of 12 months. You must have a return authorization number to service your product. Please contact F.dotson@chicagopartsnetwork.com to obtain an authorization number. (Gaohdc-600B hall current issue series sensors was posted and is owned by: Frankie Dotson) |
