1 - 2 Layers Low Cost PCB Manufacturing 200 square inch Cooperate with professional electronic OEM/ODM manufacturers in China, we are able to provide a great PCB Manufacture service and electronic elements assembly service. For the first time, designing circuit boards and manufacture is simple for the beginners and efficient for the professional.Our board manufacturing service makes top quality two and four layer PCBs and more. The PCB file can be in CadSoft Eagle format *.brd, Power PCB format *.pcb, Pertel 99 format *.pcb and contact us for other file format. Our electronic engineers will check the PCB file which you send us before manufacture. We will manufacture the print circute boards within 3 or 5 working days according to your request. Single or Double-sided boards Tin/lead or lead-free plating Includes Silkscreen(white colour, other colour also availble) and Solder mask layers(Green colour, and Red, Yellow,Black colours are also availble) Minimum hole size 0.2mm(8mil), minimum track width 0.2mm(8mil) 1-2 Layers ,FR4 material,0.062",1oz Copper Maximum size of single board is 50 inch Multiple designs on single panel is not allowed 38 USD +Total Area ( in Square inch) * 27cents/ sq inch (Board thichness<1.6mm) 6sq inch Single side PCB is 38USD + 6* 0.27USD= 39.62 USD 200sq inch Single side PCB is 38USD + 200* 0.27USD= 92 USD 45USD+Total Area (in Square inch) * 30cents/sq inch (Board thickness<1.6mm) 6sq inch Double side PCB is 45USD + 6* 0.30USD= 46.8USD 200sq inch Double side PCB is 45USD + 200* 0.30USD= 105USD NB: For PCB board thickness greater than 1.6mm, please contact us for the price. (1 inch =2.54cm, 200sq inch = 1290sq cm) For Total PCB Area greater than 200sq inch every 200sq inch add 8USD. Feel free to drop an email, we alway like to help. Correct and sufficient corresponding information Moneybookers 2. When you receive your order 1. Tracking order online or by phone We will sent an email which contains a tracking number along with the carrier's name after your order departured. So you could tracking your order online or by phone. 2. Contacting us when delivery go wrong. Our exprienced engineers are able to help you tranfer your schemtic to PCB format at a low price. (Low cost 1-2 layer pcb manufacture 200 square inch was posted and is owned by: Bob Pruitt) |
Bpruitt@chicagopartsnetwork.com (Bob Pruitt) for more information.
