Qty. 42; NEW Kopin CyberDisplay 320 Monochrome Framed Display Panel, Part Number: KCD-QD01-AA Comes with a manual and what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Kopin and may vary slightly due to upgrades, options, or revisions this unit may or may not have. The units are brand new in the original factory packaging. There are 42 Displays in each package! List Price: $34.00 each (for a Qty. of 10-99) Link to a Pin-Out & Dimensions: Kopin Pinout Assignment & Mechanical Specifications Datasheet The CyberDisplay 320 is an active-matrix liquid crystal display, with 320 x 240 spatial resolution. The display is fabricated in a high speed, low power CMOS process utilizing single crystal silicon-on-insulator (SOI) starting material. The display's integrated horizontal and vertical shift registers with thin film transistors meet the performance demands of high-speed video applications. The display uses complementary analog video inputs. All digital control inputs accept 3.3 - 5.0 volt levels. * 320 (H) x 240 (V) spatial resolution (76,800 pixels) * Active pixels 320 x 240 (76,800 pixels) * 3.3 - 5.0 volt CMOS logic compatible control signals with built-in level-shifter * Low power consumption: 12 mW * High performance: up to 72 frames per second * 1 positive and 1 negative polarity staggered analog video inputs * Integrated horizontal and vertical shift registers * Right to Left or Left to Right Scanning * Ultra-compact size: Active display area 4.80 mm x 3.60 mm (0.24 inches diagonally) Voltage-Transmission Characteristics: Line Stick Retention Intensity: 1. Ratio of white image/black image (White 0, Black 3.5V). 2. Drive voltages specified are half peak-to-peak amplitudes. 3. Parameters tON and tOFF measure 90-10% and 10-90% transitions respectively. 4. 20log (50 Hz AC / DC) with 50% gray image. 5. 20log (25 Hz AC / DC) with alternating black and white columns. 6. Decay time to less than 1% full gray scale. 7. 20log (25 Hz AC / DC) with 50% gray image. 8. 5-point measurement of percent transmission, reporting maximum difference from center. 9. 5-point measurement of CIE 1976 color coordinates, reporting radius in (u', v') space. 10. Absolute difference in color temperature of light entering and exiting unpowered display. Typical backlight color temperature is 8000K. Press Release that I Found on the Web (not sure how accurate it is): The new Panasonic brand digital camcorders should be available in the United States and Canada starting this month. The model numbers of the new camcorders are PV-602, DV702, DV402, DV202, DV102, PV-DV102, and PV-DV52. Kopin's CyberDisplay is a 0.24-inch diagonal transmissive active matrix liquid crystal display (AMLCD) that displays information at a pixel resolution of 320 x 240. At 1,700 lines per inch, it is the world's densest AMLCD. Along with displaying standard text and graphics, the CyberDisplay operates at video speeds and consumes less than 20mW of power, including the backlight. The CyberDisplay offers original equipment manufacturers (OEMs) a power-efficient, lightweight and cost-effective display option for a range of devices from consumer electronics such as camcorders and digital cameras to next-generation Internet wireless handsets. For More Pictures Please Click the Following: (Kopin cyberdisplay 320 monochrome display .24" was posted and is owned by: Jami Leblanc) |
