AIDA MODEL NC2-110(1) DOUBLE CRANK GAP FRAME PRESS* Shut Height Over Bed (SDAU): 18.7" Slide Adjustment (Motorized): 3.54" Slide Face Area: 53.5" L-R x 20.4" F-B (T-Slotted) Speed (Variable): 50 - 100 SPM Air Clutch and Brake with Selector Controls Arranged for (3) Knockouts F-B Air Counterbalance Cylinder to Slide T-Slotted Bolster Plate (5" Thick) 15 HP AC Main Drive Eddy Current Motor Dual Palm Button Operation (Pedestal Mounted) Approximate Overall Dimensions: 84" L-R x 70" F-B x 115" H Approximate Weight: 40,000 Lbs. Serial Number: 10511-1150 (New 1987) P2 F.O.B. Elk Grove, IL - $ 64,500.00 * PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION Email us at L-simon@chicagopartsnetwork.com Call our Sales Staff at 1-(***)-254-8808 Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes. Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power. 1-(***)-427-3333 (outside US & Canada) Email: L-simon@chicagopartsnetwork.com (Aida NC2-110(1) double crank gap press was posted and is owned by: Lula Simon) |
