Modbus Plus to EtherNet/IP Communication Module The ProLinx family Modbus Plus to EtherNet/IP communications module (5303-MBP-DFNT) creates a powerful connection between devices on an EtherNet/IP network and a Modbus Plus device. The module is a stand-alone DIN rail-mounted protocol gateway that provides one Modbus Plus configurable DB9F port and one Ethernet port. The Modbus Plus protocol driver exists in dual Modbus Plus Ports (MBP). The driver can be configured on an individual port basis as either a master or a slave to interface with other Modbus Plus devices. The Modbus port is fully configurable, providing a great deal of flexibility. The Ethernet/IP (DFNT) protocol driver supports the Explicit Messaging implementation of the protocol. User-configurable as both a Client and a Server, the EtherNet/IP port is a very powerful data transfer tool. The MBP-DFNT modules are the ideal solution for the many applications where EtherNet/IP connectivity can be used to integrate a Modbus Plus device into a system. The EtherNet/IP gateway is a powerful module designed with both Client and Server support, enabling easy connection to Rockwell Automation PLCs (CLX, SLC, PLC, CPLX, and similar devices). In combination with the Modbus Plus support, the module provides a very powerful interface to the many Modbus Plus devices which are in use in the industrial marketplace today. Applications for the module are found in most industries, especially the Manufacturing, Oil and Gas, Electrical Power and Food Processing. The ProLinx module contains an internal database that consists of areas for application data, status information, and configuration information. The internal database is shared between all ports on the module and is used as a conduit to pass information from a device on one network to one or more devices on another network. The data area is used to store and retrieve data by the protocol drivers and for data exchange between protocols. The database is used as a source for write commands to remote devices and holds data collected from the remote devices. Commands defined in the configuration file (stored in the configuration data area) control how the data is to be handled in the database. This area is used to store error codes, counters, and port status information for each port. This file contains module configuration information such as port configuration, network information, and command configuration. This configuration file is downloaded to, or uploaded from, the module. Modbus Plus Port Specifications The Modbus Plus protocol driver exists in dual Modbus Plus Ports (MBP). The driver can be configured on an individual port basis as either a master or a slave to interface with other Modbus Plus devices. 3 : Read Multiple Data Registers (MSTR 2) 16 : Write Multiple Data Register (MSTR 1) Global data read (32 words max.) Global data write (32 words max.) Modbus Plus Functioning as a Master Up to 200 commands on the master port, fully configurable for function, slave address, register to/from addressing and word count Error codes available on an individual command basis. In addition, a slave status list is maintained per active Modbus Master port. Configurable polling of command list, including continuous and on change of data Modbus Plus Functioning as a Slave Error codes, counters and port status available on the configured slave port EtherNet/IP Protocol Specifications The EtherNet/IP protocol is one of the primary connectivity tools to the different Rockwell Automation platforms. The Explicit Messaging aspect of the protocol (only) has been implemented in the ProLinx units to provide the data transfer link between the ProLinx units and the Rockwell Automation hardware. (Implicit Messaging (I/O communications) is not supported) Compatible devices include a wide assortment of other client/server devices such as: PLC5/E Rev. C/N, D/E, E/D or later SLC5/05 Series A, OS503 frn4 or later ControlLogix processor via 1756-ENET Interchange (release dependent) RSLinx Gateway V1.7 or later 125 word read and write data lengths EtherNet/IP Server Specifications When in the Server mode, the module accepts commands from one or more clients to read/write data stored in the module's internal registers. Five (5) independent TCP server sockets permit remote clients to interact with all data contained in the module. Data Table File Start - Fixed at N10 Data Table File Size - 100 or 1000 words 0x00 WordRange Write (Binary Address) 0x01 WordRange Read (Binary Address) 0x00 WordRange Write (ASCII Address) 0x01 WordRange Read (ASCII Address) 0xA1 Prot Typed Read w/ 2 addr fields 0xA2 Prot Typed Read w/ 3 addr fields 0xA9 Prot Typed Write w/ 2 addr fields 0xAA Prot Typed Write w/ 3 addr fields EtherNet/IP Client Specifications When configured in Client mode, the module controls the read/write data transfer between the gateway and other Ethernet/IP devices. When configured in this mode, data transfer can be initiated and executed without any ladder programming being required in the Rockwell Automation hardware. Support for 100 commands, each configurable for command, IP address, register to/from addressing and word/bit count User configurable polling of commands, including disabled, continuous and on change of data (write only) 0x26 Read-Modify-Write (Binary Address) 0x26 Read-Modify-Write (ASCII Address) 0xAB Prot Typed Write w/ Mask 3 addr fields Error codes available on an individual command basis. EtherNet/IP (Explicit Messaging) Compatible Devices List of Rockwell Automation material that support EPIC: SLC5/05 series A, OS503 frn4 MicroLogix 1100/1400/ANY via 1761-NET-ENI CompactLogix 1768-L43/L45 via 1768-ENBT CompactLogix 1769-L32E/L35E/ANY via 1761-NET-ENI ControlLogix 1756-ENET/ENBT/EN2T Positive, Negative, GND Terminals Serial Activity and Error LED Status (Ethernet protocol gateways only) 10Base-T half duplex RJ45 Connector Link and Activity LED indicators Electrical Isolation 1500 V rms at 50 Hz to 60 Hz for 60 s, applied as specified in section 5.3.2 of IEC 60950: 1991 Ethernet Broadcast Storm Resiliency = less than or equal to 5000 [ARP] frames-per-second and less than or equal to 5 minutes duration Application Serial Ports (Serial protocol gateways only) RS232 handshaking configurable RS-422/485 DB-9 to Screw Terminal Adaptor Note: The number of serial application ports depends on the module type, and the combination of protocols. 2500V RMS port signal isolation per UL 1577 3000V DC min. isolation port to ground and port to logic Mini-DIN to DB-9M serial cables 4 ft RS-232 configuration cable CD (docs and Configuration utility) RS-422/485 DB-9 to Screw Terminal Adaptor for each serial application port (serial protocols only) (Aeg gould modicon prosoft prolinx 5303-mbp-dfnt was posted and is owned by: Minerva Macdonald) |
minervamacdonald@chicagopartsnetwork.com (Minerva Macdonald) for more information.
