2-Layer PCB Manufacture Service 1 Please read the following messages carefully before placing your order: 1. In PCB made-to-order service, we provide green paint and white silkscreen only. 2. In PCB made-to-order service, we provide 1 oz of copper only, which is approximately 35um 3. In PCB made-to-order service, we provide 1.6 mm FR-4 glass-based fiber PCB only. 4. We don t provide RoHS-compliant PCB for Service 1 - 5. 5. The width of line must be larger than 8mil; the distance between two lines must be larger than 8mil. 6. The diameter of the drilled hole should be no less than 10mil, which is approximately 0.25mm. Gerber RS-274X,dsp,99fe,protel PTH/ NPTH 0.08/0.05 mm for 0~0.85mm hole 0.1/0.08 mm for 0.85-1.6mm hole 0.15/0.1 mm for 1.65-5.0mm hole Immersion Tin or Immersion Gold Send Gerber-based PCB files to our mailbox (elise-higgins@chicagopartsnetwork.com.) and make sure they can meet the requirements that Sure Electronics has set for format and file name, which include: 1. Top (copper) Layer : .GTL 2. Bottom (copper) Layer : .GBL 3. Top Overlay Silkscreen : .GTO 4. Bottom Overlay Silkscreen: .GBO 6. Bottom Solder Mask : .GBS Note: Missing any one of the above files will be deemed as intentionally left blank. Meanwhile, another txt document is also required, in which the following shall be expressly described: 1. Form factor: e.g. 10 inches x 10 inches or 2.54 cm x 2.54 cm Note: We don't accept the requirements of having two different designs implemented on a single board. It will take 10 to 15 days to complete the manufacture. When you receive the parcels, remember to mail us. Each PCB area 100 cm2 (16 inch2) The length of each PCB should be less than 20 cm Each PCB area 250 cm2 (35 inch2) The length of each PCB should be less than 40 cm Total PCB area 0.5 m2(800 inch2) The area of each PCB should be less than 500 cm2 If you need more than 2 m2 (including 2 m2 ), (Low cost 2-layer pcb manufacture service 1 (5 boards) was posted and is owned by: Elise Higgins) |
