Tektronix P6249 PROBE, ACTIVE; 4 GHZ BANDWIDTH, 1.75V DYNAMIC RANGE-CERTIFICATE OF TRACEABLE CALIBRATION STAND Performance Characteristics of the P6249 The P6249 Active FET Probe is a primarily used for the TDS694C and TDS794D high performance scopes. It may also be used with conventional BNC interfaces via the Tektronix 1103 TEKPROBE Power Supply * <120 ps Rise Time (Guaranteed) * <0.5 pF Input Capacitance (P6241 Only) * Small Form Factor Probe Head * 8 Vp-p Dynamic Range (P6241 Only) * P6249 TDS/CSA7000B, 6000B, 700, 600 Series * P6241 TDS/CSA7000B, 6000B, 700, 600 Series * P7240 TekConnect™ Interface * P6249 TekProbe® II BNC Interface * P6241 TekProbe II BNC Interface * High-speed Digital Systems Design * Component Design/Characterization * Signal Integrity, Jitter and Timing Analysis * Manufacturing Engineering and Test * Signals with Voltage Swings up to 8 Vp-p * Measures 3.0 V Logic, InfiniBand, PCI Express, DDR, Rambus Data Lines, Gigabit Ethernet TekProbe BNC Interface - P6249 and P6241 The P6249 and P6241 have similar performances to the P7240. Primarily used for the TDS694C and TDS794D performance scopes, these probes may also be used with conventional BNC interfaces via the Tektronix 1103 TekProbe Power Supply. The P6249 provides 4 Vp-p dynamic range. The P6241 offers a 10X attenuation and a 8 Vp-p dynamic range plus has a lower input capacitance due to the unique probe tip. A full complement of versatile probe tip accessories helps users connect to the wide range of devices faced by digital designers. (Tektronix model:P6249 4 ghz 5X active probe was posted and is owned by: Mayra Holman) |
