Amada CNC Production Cut-Off Saw CM-100-AN .75" to 3.9" http:// /watch?v=D4Kw1tby-tA Amada CNC Production Cut-Off Saw economical and efficient metal sawing operation. These features coupled to a bundle incline magazine loader, produce the lowest possible cost per cut. Extreme accuracy and milled finishes helps to reduce costs by eliminating secondary operations. The saw blade and vises are completely enclosed which allow this machine to have high production rates and reduce noise levels within the acceptable limits. The mist coolant system and automatic chip conveyor help to keep the machine and adjacent areas Cutting Capacity, Rounds: .750" to 3.9" Cutting Capacity, Squares: .750" to 3" Blade Size: 14" OD x 0.100" x 1.250" Bore Saw Blade Feed Rates: Variable by Hydraulic Cylinder Automatic Material Feed Length: 0.2" - 999,999" (Variable Index) Material Feed Length Single Stroke: 0.2" - 23.6" Rate of Material Feed: 29 IPM Overall Dimensions: 66" x 85" x 60" (not incl. magazine) 17' Inclined Type Automatic Loading Table for Continuous Cutting Sorting Device to Separate Trim & Remnants from Good Pieces Controlled Mist Coolant System - Eliminates Flood Anti-Backlash Device for Maximum Blade Life Ammeter Monitoring Main Motor Amp Draw Length Setting by Direct Read-out Self-Diagnostics by Error Codes Wire Brush for Chip Removal 15 HP Main Motor Drive 230/460/3/60 Approximate Net Weight: 5,400 Lbs. (Amada cnc production cut-off saw cm-100-an .75" to 3.9" was posted and is owned by: Ivy Cochran) |
I_cochran@chicagopartsnetwork.com (Ivy Cochran)
for more information.
