This meter is a portable professional measuring instrument with LCD and back light easily reading. The single-hand operation design for the range switch makes measurement simple and easy. Overload protection and low battery indication are provided. It is an ideal multi-function Instrument with scores of practical applications for professional, workshop, school, hobby and home use. Conform to the IEC61010-1 & IEC61010-032 standard Double insulation (protection class 600V CAT III and pollution degree 2) The over-molding rubber case protects the meter to be stronger Maximum/minimum value measurement DC voltage: 660m/6.6/66/600V 0.8% AC voltage: 660m/6.6/66/600V 1.0% Resistance: 660/6.6k/66k/660k/6.6M 1.0%, 66M 2.0% Capacitance: 6.6 /66 /660 /6.6m/66mF 4.0% Frequency: 10 to 10kHz 2.0% (from test terminal) Frequency: 10 to 1kHz 2.0% (from current clamp) Continuity checking with buzzer MAX. Diameter for conductor: 26mm Notes: User manual not included in the package, Please click here to download it! (6600 counts rms ac/dc current digital clamp multi meter was posted and is owned by: Sylvia Stanley) |
