FACTORY MODEL NC-4109-5, 3 VOLTS. The Robertshaw (formerly Eaton) Dual Gas Valves are thermal bimetal gas control valves designed for efficient use in gas cooking appliances of various types. They are especially good for home use because they are quiet operating. The oven safety valves with dual outlets are usually used in selfclean ovens. Because these valves are fully ambient temperature compensated, positive shut-off and repeatability of opening and closing times are assured. They are normally closed, which means they open when voltage is applied. Any interruption in the electrical circuit will cause the valve to close. All thermal bimetal gas valves are design certified for use with natural, LP, manufactured and mixed gases. For LP gas installation, the orifice hood should be screwed down against the hood pin. For natural gas installation, the hood should be backed off two to three turns from the hood pin. Dual gas valves are designed for 4" of inlet pressure using natural gas and 12" of inlet pressure using LP. Standard operating pressure for these valves is 1/2 PSI (1 PSI = 27" of pressure). Their ambient temperature range is 32- 300 F. FRIGIDAIRE 77411160012 TAPPAN 774T116P12 OUTLET: 3/8" TUBE WITHOUT FITTING X ORIFICE 1/4" M(2), 3/16" M(2) TERMINALS-BRACKET MOUNT (Robertshaw y-30172-AF2 dual bimetal gas valve nc-4109-5 was posted and is owned by: Mario Kane) |
