ImageDurand Wayland AF500CPS 500 Gallon Tractor Orchard SprayerImage Stainless Steel construction, Myers 130 GPM Centrifugal Pump, Fan Blown Chemical This sprayer is PTO driven at 540 RPM's to a Myers 2C95 200 PSI 130 GPM centrifugal pump. To the best of my knowlege the sprayer was manufactured in 1989 and has been used to spray pesticides on peach trees. This sprayer has been well maintained and was flushed after each use. The fan is a 36" (920mm) axial flow 8 bladed fan with die cast aluminum hub. The fan is coupled to a 2-speed gearbox with a neutral. There is a water return going into the stainless steel wash basket in the tank lid. All plumbing is non-corrosive. There are 4 straining points on the sprayer: tank neck, suction strainer, inline strainer and nozzle strainer. Wheels are adjustable in height. There are eight different height settings. Sight gauge is located on front of tank. 14L x 16.1 tires standard. Constant velocity PTO shaft. Recommended tractor HP variable from 40 to 75 HP. Rollover ceramic nozzles, 10 per side, with diaphragm check valves standard. Product Features & Specifications: * Myers 2C95 130 GPM 200 PSI centrifugal pump * PTO Driven (540 Maximum RPM's) * Tractor mounted flow controls The Item location is Paris, Tn. * Please Contact us with any questions. Rest assured your information will not be given, sold, rented or loaned to any third party for any purpose. (Durand wayland 500 gallon tractor orchard sprayer was posted and is owned by: Charlie Rivas) |
Crivas@chicagopartsnetwork.com (Charlie Rivas) for more information.
