ELECTRIC TRUCK CIRCUIT DIAGRAMS An Aid To Better Understanding Of Clark Electric Industrial Trucks This reference manual measures 9 1/2" x 11 1/2", and has 5 pages and 83 diagrams. It is weathered and stained, but all the pages and diagrams are intact and in good shape. Pages and diagrams are 3-hole punched and in a dark green binder with a clear front cover which has a few tears and a permanent crease from top to bottom. Original price $2.00. The first three pages are headed with: Machine Index Circuit Diagrams - Clark Electric Industrial Trucks and each page has three columns - Machine Model - Contactor Panel - Circuit Diagram. The last two pages are headed with: Numerical Index Circuit Diagrams - Clark Electric Industrial Trucks and each page has three columns - Circuit Diagram - Machine - Contactor Panel. Many models are included. If you are interested in a particular one, please e-mail me with your questions. (Clark equipment electric truck circuit diagrams - 1965 was posted and is owned by: Casandra Shields) |
C_Shields@chicagopartsnetwork.com (Casandra Shields)
for more information.
