26 FT3 MAC COMET BIN WITH LUMPBREAKER & SCREW FEEDER CARBON STEEL CONSTRUCTION. COMET RECEIVER WITH 9" DIA. X 40" LONG FLARE TROUGH SCREW CONVEYER. 1-1/2 HP BALDOR MOTOR, 1740 RPM, 575 VOLT, 145TC FRAME. DODGE TIGEAR REDUCER, CHAIN DRIVE WITH GUARD. INTERNAL LUMPBREAKER WHICH IS SLAVE DRIVEN OFF THE TAIL END OF THE SCREW CONVEYOR. THE SCREW CONVEYOR HAS AN 8" OUTLET. 29" OUTLET DISCHARGE HEIGHT. THE TOP INLET IS 6" DIA. 150# FLANGE. THE HOPPER ALSO HAS TWO 3" O.D. TANGENTIAL INLETS. THE STRUCTURE AND CONTROL BOX ARE ALSO INCLUDED. OVERALL DIMENSIONS: 58" W X 60" D X 102" H. (26 FT3 mac comet bin with lumpbreaker & screw feeder was posted and is owned by: Kelli Warren) |
kelli-warren@chicagopartsnetwork.com (Kelli Warren) for more information.
