This JLG Parts Manual is for a 1532E, 1932E, 2033E, 2046E, 2646E, 2658E. The book shows the Date of April 1997 and Change of June 1 1997. This is an excellent manual. The manual has minor smudges on the front book front cover. All the pages are clean inside. The book breakdown includes Frame, Ground Components,Scissor Arms, Platform, Cylinders, Hydraulics , Electrical, Decals and Special Options This is a great manual for reference and has Electrical and Hydraulic Schematics for troubleshooting. Parts book is approximately 1/2 Inch thick. I have been working on lifts for 21 years if I can help you or answer any questions - Please do not hesitate to ask. BONUS - ALSO INCLUDED IS A GLOSS PAPER SINGLE PAGE 11"W x 17"L ELECTRICAL SCHEMATIC. THIS IS A EXTRA LONG PAGE THAT SHOWS ALL THE ELECTRICAL ON ONE PAGE. THIS IS A TIME SAVER WHEN TRACING WIRING. (Jlg part manual & schematic , 1532E 1932E 2033E 2646E was posted and is owned by: Nell Kim) |
n.kim@chicagopartsnetwork.com (Nell Kim) for more information.
