4x~200x Binocular Zoom Stereo Microscope (M421) With Add-on 2x, 0.5x Auxiliary Objective Lens Plus 76mm Thread Extension Sleeve * Zoom lenses 4x~200x, crystal clear within any range * Extra 2X auxiliary lens double the magnification of original objectives * Extra 0.5X auxiliary increase working distance combined with extension sleeve * Dual upper and lower LED matrix illuminators * Sharp erect stereo images over a super wide field view * Slot on objective housing for easy mounting ring lights (sold separately) * Eyepiece mounting size: 30.0mm in diameter * Wide field EW10X/22 eyepieces with diopter adjustment * WF20X/12 eyepieces with built-in rubber ring to comfort eyes * Adjustable diopter with clear scale for the different visions * Total magnification: 4x~200x * Interpupillary distance: 2" ~ 2-15/16"(52~75mm) * Working distance: 4-1/2" (115mm) * With 2X auxiliary objective lens: working distance: 1-1/2" (38mm) * With 0.5X auxiliary objective lens and extension sleeve: working distance: 6-3/4 " (172mm) * Incident (upper) illuminator: 30 LED matrix * Transmitted (lower) illuminator: 60 LED Matrix * Lifetime of LED: 100,000 hours * Each light has its own intensity control * 2X auxiliary objective lens: thread 54mm in diameter; Thickness: 22.5mm; Outside diameter: 60mm; Interior glass diameter: 45mm * 0.5X auxiliary objective lens: thread 54mm in diameter: Thickness: 19mm; Outside diameter: 60mm * Metal extension sleeve: 76mm thread diameter; Thickness: 79mm * Clear glass stage plate: 100mm in diameter * White/black plastic stage plate: 100mm in diameter * Power supply: 100V-240V 50/60Hz wide range worldwide * Dimension: 11-1/2 " x 9-1/2" x 13-3/8" (29.1cm x 24cm x 34cm) * A pair of WF10X/22 eyepieces * A pair of 30mm WF20X/12 eyepieces * Metal 0.5X auxiliary objective (D54mm) * Metal 2X auxiliary objective (D54mm) * Metal 76mm thread extension sleeve Click the button above to see compatible accessories for this product XM421B (Binocular zoom stereo microscope 4-200X upper/lower led was posted and is owned by: Susanna Kidd) |
Skidd@chicagopartsnetwork.com (Susanna Kidd) for more information.
