http:// /store/products.asp?cat=17- Rompas Block-$270 That's over $2000 and that is not even including the unit, case and all the accessories. the Sonic 1000S/1200S Series offers the highest ultrasonic resolution of any lightweight portable ultrasonic flaw detector. It's innovative design features an uncluttered keypad, and Smartknob , making it extremely simple and intuitive to train on and to operate. The new Sonic 1000S+ / 1200S+ has all of the features of the standard Sonic 1000S / 1200S, PLUS they operate with the latest color LCD display module, provide VGA output with color display, and is configured with a single 6. 6AH Li-Ion battery for a total weight of less than 4 pounds! Pulser-type: square wave. 150/300V selectable Tuning range: 1MHz, 2.25MHZ, 5 MHz, 10 MHZ Wideband (0.3 - 20MHz) Gates: Two flaw gates with peak amplitude of gated signals Rep Rate: 50Hz-3450Hz, 50 Hz increments Range: .048" - 296" at steel velocity A-scan storage: up to 100 A-scans Thickness gauge: E-E of IP-1st (manual or auto), peak or edge trigger. Trig Calculations. Peak hold with active echo DAC with 25 operator selected segments Data logger: up to 5000 measurements RF thickness gauging and flaw detection Weight: 3-6 pounds depending on battery configuration Battery choice: dual Ni-MH, single Li-Ion, or D cell (Olympus staveley 1200S ultrasonic flaw detector ndt was posted and is owned by: Margarita Ballard) |
margarita_ballard@chicagopartsnetwork.com (Margarita Ballard) for more information.
