Specs on the unit are as follows: * Output: +3 dBm min into 50 ohms, +7 dBm typical * Oper. Temp. Range: -40 degree C to +65 degree C * Temp Stablilty & Aging: +-5.0 ppm max for 17 years, +-5 x 10(-7) typical for temp stability * Supply Voltage: +12 Vdc (+-5%) * Current: 350 mA max at turn on * Power Consumption: 4.2 Watts max at turn on, 1.2 Watts typical stabilized at +25 degree C * Voltage Control: +-3 x 10(-6) typical for 0 to +5 volts, Negative Slope * Phase Noise: -115dBC - 100Hz, -139dBc - 1KHz, -151dBc - 10KHz, -154dBc - 100KHz (100 mhz voltage controlled crystal oscillator , bliley was posted and is owned by: Calvin Mccarthy) |
C.mccarthy@chicagopartsnetwork.com (Calvin Mccarthy)
for more information.
