PINES MODEL 4 HYDRAULIC ROTARY TUBE BENDER* Average Maximum Bending Arm Speed: 1.5 RPM (Forward) Standard Operating Pressure: 2,000 PSI Maximum Bend Angle: 180 Degrees (+ Overbend for Springback) Counter Clockwise Bending Rotation (8) Station Turret Degree-of-Bend Selector Hydraulic Bending Speed Control Valve Bijur Automatic Lubricating System 20 HP AC Main (Pump) Drive Motor 460/3/60 Electrical Controls (Separete Cabinet) Swinging Arm Safety Device; Multiple PB Operation (Pedestal Mtd.) Non-Ferrous Tubing Y.P. to 12,000 PSI: 6" O.D. x .300" Wall Non-Ferrous Tubing Y.P. to 25,000 PSI: 6" O.D. x .250" Wall Steel Tubing Y.P. to 40,000 PSI: 6" O.D. x .165" Wall Stainless Steel Tubing Y.P. to 60,000 PSI: 4-1/2" O.D. x .250" Wall Square Tubing (Mild Steel): 4" x .250" Approximate Overall Dimensions: 212" L-R x 84" F-B x 54" H Approximate Weight: 13,000 Lbs. Serial Number: 11420-78337 (New 1978) P2 F.O.B. Elk Grove, IL - $ 57,500.00 * PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION Email us at A.anthony@chicagopartsnetwork.com Call our Sales Staff at 1-(***)-254-8808 Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes. Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power. 1-(***)-427-3333 (outside US & Canada) Email: A.anthony@chicagopartsnetwork.com (Pines 4 tube bender was posted and is owned by: Arline Anthony) |
A.anthony@chicagopartsnetwork.com (Arline Anthony) for more information.
